Containers

Container OFFICE CONTAINERS

Building a traditional office requires plenty of work and involves high cost. Therefore, we offer office containers as a modern and more effective solution. These cost-efficient facilities are not permanently connected to the ground, thus offering a mobile solution.

The versatility of containers offered by ICONTAINERS makes them suitable for use as staff, residential or locker room facilities.

phone.: +48 531-241-672
phone.: +48 535-986-808
e-mail: [email protected]

Technical data

TECHNICAL DATA
DIMENSIONS– external: 6006 x 2430 x 2850 mm
– internal: 5750 x 2150 x 2500 mm
STRUCTURE– steel structure made of 4 mm thick steel sections according to EN 10025-2:2019 / EN 10025-2:2019 / EN 10051-10;
– corner posts firmly welded to the floor and roof structure;
– all coated with polyurethane paint (RAL 7016);
– lifting lugs for handling,
ROOF– 4 mm thick steel sections;
– corner reinforcements made of 4 mm metal sheet;
– sandwich panel with 100 mm polystyrene core, double laminated with 0.5 mm metal sheetheat transfer coefficient ‘U’ for BAAS-PANEL D roof panels (0.54 to 0.14) [W/m2K];fire classification according to PN-90/B-02851degree of fire spread: NROfire-resistance rating: RE30 for roof;
– roof finishing accessories of 0.5 mm sheet;
– sealing: 0.5 mm galvanized sheet;
– finishes: 0.5 mm coated sheet (RAL 9010);
WALLSY– 100 mm sandwich panel with a polystyrene core;
– exterior wall: 0.5 mm micro-corrugated sheet (RAL 9006);- interior wall: 0.5 mm smooth metal sheet (RAL 9010);
– perimeter trims of 0.5 mm metal sheet (RAL 9010);
– fire classification according to PN-90/B-02851degree of fire spread: NRO fire-resistance rating: E90 for walls, RE30 for roof;
FLOOR– a strip of Z-sections firmly welded together;
– insulated with 100 mm mineral wool (λD = 0.044 W/mK according to PN-EN 13162:2013-05), GUM Technical Approval: 68/322/71/2016;
– floor sealing with 1 mm galvanized metal sheet;
– floor base: 22 mm DURELIS p5 panel;
– 2.5 mm vinyl flooring with abrasion resistant coating;DECLARATION OF PERFORMANCE V434,EN ISO 10874 performance classification: 33-42; according to EN 14041:2004/AC:2006;
– skirting boards (RAL 9010);
DOORS– 200/80 cm external solid steel door (RAL 7016);
– 200/90 cm door with reinforced wood and steel structure with double lock, three bolts and three hinges (RAL 7016);
– internal solid doors (RAL 9010); Declaration of Conformity No. 92/02/2014/HP/KOM/DPO for steel doors Building Research Institute Technical Approval No. AT-15-3435/2014
WINDOWS– Ideal 4000 tilt and turn window (RAL)installation depth: 70 mm Uw coefficient ≤ 1.3 W/m2K; five-chamber profile;
– 120 x 120 cm Ideal 4000 tilt and turn window (RAL 7016)
– 100 x 100 cm Ideal 4000 tilt and turn window (RAL 7016)
– 80 x 100 cm Ideal 4000 tilt and turn window (RAL 7016)
– 53 x 56 cm Ideal 4000 tilt window (RAL 7016)
– serving window;-RAS137 adaptive external roller shutter(adjusted to the window size)
ELECTRICAL SYSTEM– 5x32A electrical connection
Declaration of Conformity No. 21/2019 RoHS Directive 2011/65/EU; Low Voltage Directive 2014/35/EU; Standards: PN-EN 60309- 1:2002/A 1:2009+A2:2013.03 and PN-EN 60309 02:2002/A1:2009+A2:2012;
– 12 module surface-mounted switchboardEC DECLARATION OF CONFORMITY No. 34/2011; No. 19/2012
– residual current and overcurrent protectionDeclaration of Conformity (in accordance with ISO/IEC 17050-1) No. 18/03/2017;Compliant with the standards: EN60898-1/03 + A1/04 + A11/05 + A12/08 + A13/12 ;Low Voltage Directive 2014/35/EU; RoHS Directive 2011/65/EU
– LED lamp;
– double hermetic (IP54) sockets Declaration of Conformity No. K-S/170/2010, Standard: PN-EN 60669-1:2006 PN-IEC 60884-1:2006 and
– IP54 single-pole switch
HEATING– 2000 W convection heater
– gravity ventilation
KITCHEN FACILITIES– base cabinets – 180 cm (80 cm sink cabinet, sink, 60 cm fridge + 40 cm cabinet with a drawer and a worktop);
– upper cabinets (80 cm + 60 cm + 40 cm);
– single-bowl inset sink with a Deante Tango drainer;
– under sink tankless water heater– 3.7 – 5.5 kW
SANITARY FACILITIES– Kerra C-clear freestanding toilet unit;
– Koło Idol washbasin with Ferro Rosa single-lever mixer;
– a shower enclosure with a shower tray / square shower tray with a curtain and a rain shower;
– BOSCH Tronic 2000 electric water heater – 18 kW;
– Roca Euret urinal with a drain valve
ACCESSORIES– 2.6 kW HAIER air conditioner with an auxiliary heating function;European legal acts:
Low Voltage Directive 2014/35/EU;
Electromagnetic Compatibility Directive 2014/30/EU;
ROHS: Directive 2011/65/EU of the European Parliament and of the Council on the restriction of certain hazardous substances in electrical and electronic equipment
WEEE: Directive 2012/19/EU of the European Parliament and of the Council on waste electrical and electronic equipment.

OFFICE CONTAINERS

Gallery

Check what our containers look like
